Dissecting Scope

This tool requires common sense.
The steward for this tool is: Simon Clark

Motic dissecting scope with integrated USB1 camera.

History

Has 10x and 30x magnification which is more than enough for surface mount components.

Location

Electronics area.

Issues

None. Works perfectly.

History and Ownership

This item came Simon Clark at Digital Frog International. It now belongs to Diyode. I tried to eBay it for the laser fund, but could not get a decent price for it.

Details

Product information : DC2-456 (current model DC4-465H)
Windows Softare : Plus2.0ForPC.zip

Camera uses the Motic 2E USB2 driver for Windows XP
Maximum resolution for this model is 640x480.
